PCB Assembly Services
What assembly variants are supported?
SMT, THT, mixed technology, and single/double-sided placement are all supported across prototype and production requirements.
What solder paste types are available?
Leaded and lead-free (RoHS compliant) solder paste options are available depending on project and compliance requirements.
What component types and sizes are supported?
assive components as small as 01005, BGA, and fine pitch parts are supported. Maximum component size is 56 x 56 x 15 mm. Minimum BGA pad size is 0.20 mm.
What are the BGA and QFN clearance requirements?
Clearance greater than 0.17 mm is standard. Clearance between 0.15 mm and 0.17 mm requires a dam. Clearance below 0.15 mm is not feasible.
What is the minimum order quantity?
There is no minimum order quantity — assembly services are available for single prototype boards through to full production runs.
What component package formats are accepted?
Reels, cut tape, tube and tray, and loose parts are all accepted component package formats.
What PCB materials are supported?
FR4, Rogers, and MCPCB materials are supported. Flexible PCBs are subject to availability.
What quality inspection methods are used?
Visual examination, X-ray inspection, and automated optical inspection (AOI) are applied across assembly projects.
What file formats are accepted?
BOM files (.xls, .csv, .xlsx), Gerber (RS-274X), and centroid files are accepted for PCB assembly orders.
Start Your PCB Assembly Project
Share your project requirements and a member of the PCB Power team will get in touch to discuss your assembly needs.
Industries We Serve
PCB Power supports application-specific PCB requirements across defense, aerospace, medical, automotive, robotics, and industrial electronics sectors.
Why Choose PCB Power
Reliable PCB services for engineers and teams across the United States — from prototype to production.
Complete PCB Services in One Place
Layout, fabrication, assembly, sourcing, stencil, and turnkey — all through one coordinated workflow.
Advanced Technical Capabilities
Support for complex PCB requirements across demanding industries and specialized applications.
Quick-Turn and Prototype-Ready
Responsive turnaround options to keep prototype and production timelines on track.
Assured & Certified Quality
Every PCB project is handled with strict process controls and quality standards to ensure reliable, high-performance outcomes across all applications.
How to Order from PCB Power
Placing a PCB order with PCB Power is simple, transparent, and fully supported at every step.
1
Place an Inquiry
Visit the service page or contact form and share your PCB requirements along with relevant project details.
2
Get Quote
Review the detailed PCB quote and approve it to move forward.
3
Manufacturing
Your PCB order is processed through the applicable service workflow — fabrication, assembly, or both.
4
Quality Check
Each PCB goes through inspection and quality checks to meet project specifications.
5
Delivery
Your completed PCB order is packed and shipped within the agreed timeline.
Our Certifications
Certified processes that support quality, consistency, and confidence across every PCB project.
IPC Certified Process
Supports reliable PCB manufacturing through recognized industry quality standards.
ISO 9001:2015 Quality Management
Reflects our structured approach to quality assurance and customer satisfaction.
RoHS Certified Process
Supports PCB manufacturing within defined restricted substance compliance limits.
International Traffic in Arms Regulation
Enables controlled support for defense and sensitive electronics requirements.
Defense Logistics Agency Approved
Supports access to controlled technical data for qualified defense-related projects.
Our Latest Blogs
Stay informed with useful PCB insights covering design, fabrication, assembly, production processes, and industry trends
Frequently asked questions
Here are some common questions about our company.
PCB assembly is the process of placing and soldering electronic components onto a fabricated printed circuit board. It includes SMT, THT, and mixed technology assembly methods depending on the design requirements.
PCB assembly services are supported by IPC, ISO 9001:2015, ITAR, RoHS, UL, and DLA DD2345 certified processes — ensuring compliance across commercial, industrial, and defense applications.
Surface Mount Technology (SMT) involves placing components directly onto the surface of the PCB. Through-Hole Technology (THT) involves inserting component leads through drilled holes in the board. Mixed technology assembly uses both methods on the same board.
Turnkey PCB assembly is a complete service covering component sourcing, fabrication, and assembly through a single coordinated workflow. Consigned assembly involves the customer supplying components, while combo assembly combines both approaches.
Yes. PCB assembly services are available for single prototype boards with no minimum order quantity, through to full production volumes.
